Category: Bending machine
Brand: Jialuolaser
Model: ABD-VII-F-KH
Views: 2635
Scope:
Model | ABD-VII-F-KH | |||||||||
Main function | Bending、 Twisting off、Cutting、Marking、Changing mould | |||||||||
Size | 1800*830*1100MM | |||||||||
weight | 350KG | |||||||||
Power supply | Single 220 v ± 5% 50HZ 10 A | |||||||||
Power consumption | 1.5 KW | |||||||||
Support files format | DXF/AI | |||||||||
Surrounding degrees | 5-35℃ | |||||||||
Air pressure pump | 6 kg/cm2 pressure, diameter 8 mm of gas tube | |||||||||
Rlue thickness | 0.71 mm (0.45 mm / 1.07 mm mould is optional) | |||||||||
Rlue highness | 8mm--30mm | |||||||||
Max bending angle | 90° | |||||||||
Min bending arc diameter | 0.5mm | |||||||||
Max bending arc diameter | 800mm | |||||||||
Changing mould | Yes | |||||||||
Notching(bridge/lip) | No | |||||||||
Coil-trolly | Ordinary coil-trolly | |||||||||
Note: the size can be custom-made according to customer's different request | ||||||||||
1, can achieve bending, siting at the same time, chick can support fast changing mould (only three minutes to fast switching high cutter, strip cutter for short) is a real sense of fully automatic computer machete machine, greatly improve the work efficiency.
2, supports DXF file format, can be the same as the laser machine public files, and supports the latest AI files, users avoid rescanning drudgery, greatly reduce the user workload and improve work efficiency.
3, apply to a variety of die cutting knife, wide scope of application, high flexibility, reduce the user cost of investment.
4, high precision machinery and electronic equipment guarantee the consistency of the machete.
5, high efficiency, fast curved knife, curved knife, good effect, greatly reduce the labor intensity of sword master.
6, machetes imported advanced steel processing tools and good abrasion resistance, high strength, durable, and reduce the use cost of users.
